TRANSCEND CompactFlash Card CF180I, 4GB, SLC mode WD-15, Wide Temp.
TRANSCEND CompactFlash Card CF180I, 4GB, SLC mode WD-15, Wide Temp.
843 Kč
697 Kč bez DPH
Dostupnost: Skladem v eshopu 🛈
Part no.: TS4GCF180I
Kód produktu: 24604625
Výrobce: Transcend
Záruka: 3 měsíců
Popis produktu
Transcend s SLC Mode technology is a cost-effective solution that offers performance close to that of SLC NAND flash at a more affordable price. Boasting a high-speed data transfer rate, Transcend s SLC Mode CF180 CompactFlash cards are perfect for embedded systems, medical instruments, road surveillance systems, and other industrial applications having high performance and capacity demands. Thanks to their use of Static Data Refresh technology, CF180 CF cards feature error correction capability, maintain data integrity, and have an extended lifespan.
Based on Ultra DMA Mode 5
True IDE Mode supported: UDMA0-5 (default), MDMA0-4, PIO0-6
True IDE Mode: Fixed Disk (Standard)
Operation modes supported: PC Card Memory mode, PC Card IO mode, and True IDE mode
Built-in ECC (Error Correction Code) functionality
Static Data Refresh
Erase Count Monitoring
Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
Wear-Leveling
Security Command
TECHNICAL SPECIFICATIONS
Dimensions
42.8 mm x 36.4 mm x 3.3 mm (1.69" x 1.43" x 0.13")
Pin Count
50 pin
Form Factor
Compact flash card
Storage
Flash Type
MLC NAND flash (SLC mode)
Capacity
128 MB
Operating Environment
Operating Voltage
3.3V±5% 5V±10%
Operating Temperature
Extended Temp.-25°C (-13°F) ~ 85°C (185°F) Wide Temp.-40°C (-40°F) ~ 85°C (185°F)
Storage Temperature
-40°C (-40°F) ~ 85°C (185°F)
Humidity
0% ~ 95%
Shock
1500 G, 0.5 ms, 3 axis
Vibration (Operating)
20 G (peak-to-peak), 20 Hz ~ 2,000 Hz (frequency)
Power
Power Consumption (Max.)
0.6 watt(s)
Performance
Read Speed (Max.)
up to 85 MB/s
Write Speed (Max.)
up to 70 MB/s
Mean Time Between Failures (MTBF)
3,000,000 hour(s)
Terabytes Written (TBW)
up to 210 TBW
Note
Speed may vary due to host hardware, software, usage, and storage capacity. Terabytes Written (TBW) expresses the endurance under the highest capacity.
Warranty
Certificate
CE/FCC/UKCA
Warranty
Three-year Limited Warranty
Popis produktu
CF180 & CF180ITranscend s SLC Mode technology is a cost-effective solution that offers performance close to that of SLC NAND flash at a more affordable price. Boasting a high-speed data transfer rate, Transcend s SLC Mode CF180 CompactFlash cards are perfect for embedded systems, medical instruments, road surveillance systems, and other industrial applications having high performance and capacity demands. Thanks to their use of Static Data Refresh technology, CF180 CF cards feature error correction capability, maintain data integrity, and have an extended lifespan.
Based on Ultra DMA Mode 5
True IDE Mode supported: UDMA0-5 (default), MDMA0-4, PIO0-6
True IDE Mode: Fixed Disk (Standard)
Operation modes supported: PC Card Memory mode, PC Card IO mode, and True IDE mode
Built-in ECC (Error Correction Code) functionality
Static Data Refresh
Erase Count Monitoring
Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
Wear-Leveling
Security Command
TECHNICAL SPECIFICATIONS
Dimensions
42.8 mm x 36.4 mm x 3.3 mm (1.69" x 1.43" x 0.13")
Pin Count
50 pin
Form Factor
Compact flash card
Storage
Flash Type
MLC NAND flash (SLC mode)
Capacity
128 MB
Operating Environment
Operating Voltage
3.3V±5% 5V±10%
Operating Temperature
Extended Temp.-25°C (-13°F) ~ 85°C (185°F) Wide Temp.-40°C (-40°F) ~ 85°C (185°F)
Storage Temperature
-40°C (-40°F) ~ 85°C (185°F)
Humidity
0% ~ 95%
Shock
1500 G, 0.5 ms, 3 axis
Vibration (Operating)
20 G (peak-to-peak), 20 Hz ~ 2,000 Hz (frequency)
Power
Power Consumption (Max.)
0.6 watt(s)
Performance
Read Speed (Max.)
up to 85 MB/s
Write Speed (Max.)
up to 70 MB/s
Mean Time Between Failures (MTBF)
3,000,000 hour(s)
Terabytes Written (TBW)
up to 210 TBW
Note
Speed may vary due to host hardware, software, usage, and storage capacity. Terabytes Written (TBW) expresses the endurance under the highest capacity.
Warranty
Certificate
CE/FCC/UKCA
Warranty
Three-year Limited Warranty
