Delock Converter RS-232 > RS-232 with 3 kV Isolation 600 W power surge
1019 Kč
842 Kč bez DPH
Dostupnost: Nedostupné 🛈
Part no.: 62500
Kód produktu: 22730859
Výrobce: Delock
Váha: 0,186 kg
Záruka: 6 měsíců
Popis produktu
Specifikace
Connector:
Host: 1 x D-Sub 9 pin Serial RS-232 female
Device: 1 x D-Sub 9 pin Serial RS-232 male
1 x DC 1.3 x 3.5 mm female
Data transfer rate up to 1 Mbps
Data Bit: 5, 6, 7, 8
Stopp Bit: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Signals: TXD, RXD, CTS, RTS, DCD, DSR, DTR
LED indicators for status TX / RX and power supply
Galvanic isolation 3 kV (optical isolation)
600 W power surge for the RS-232 interfaces
600 W power surge at the DC Connector
± 15 kV ESD protection for all signal pins
Power supply RS-232 interface pin 9: 12 V (optional)
Power supply: 10 - 30 V
Power consumption: ca. 50 mA
Operating temperature: - 30 °C ~ 75 °C
Relative humidity: 5 ~ 95 % (not condensing)
Storage temperature: - 40 °C ~ 85 °C
Housing material: plastic
Dimensions (LxWxH): ca. 88 x 54 x 22 mm
Accessories for mounting on 35 mm DIN rails
Specifikace napájecího zdroje
Wall power supply
Input: AC 100 ~ 240 V / 50 ~ 60 Hz / 0.48 A
Output: 12 V / 1.6 A
Ground outside, plus inside
Dimensions:
inside: o ca. 1.3 mm
outside: o ca. 3.5 mm
length: ca. 9.5 mm
Systémové požadavky
Devices with RS-232 interfaces
Obsah balení
Converter
Power supply
Mounting set for DIN rail
User manual
Balení
• Krabice
Popis produktu
This RS-232 to RS-232 isolator by Delock is designed to protect the connected components from electrostatic discharges and power surge. In addition, the galvanic isolation avoids data transmission errors by uneven ground voltages. Power can be provided through the serial interface or the included power supply. DIN rail mounting is supported.Specifikace
Connector:
Host: 1 x D-Sub 9 pin Serial RS-232 female
Device: 1 x D-Sub 9 pin Serial RS-232 male
1 x DC 1.3 x 3.5 mm female
Data transfer rate up to 1 Mbps
Data Bit: 5, 6, 7, 8
Stopp Bit: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Signals: TXD, RXD, CTS, RTS, DCD, DSR, DTR
LED indicators for status TX / RX and power supply
Galvanic isolation 3 kV (optical isolation)
600 W power surge for the RS-232 interfaces
600 W power surge at the DC Connector
± 15 kV ESD protection for all signal pins
Power supply RS-232 interface pin 9: 12 V (optional)
Power supply: 10 - 30 V
Power consumption: ca. 50 mA
Operating temperature: - 30 °C ~ 75 °C
Relative humidity: 5 ~ 95 % (not condensing)
Storage temperature: - 40 °C ~ 85 °C
Housing material: plastic
Dimensions (LxWxH): ca. 88 x 54 x 22 mm
Accessories for mounting on 35 mm DIN rails
Specifikace napájecího zdroje
Wall power supply
Input: AC 100 ~ 240 V / 50 ~ 60 Hz / 0.48 A
Output: 12 V / 1.6 A
Ground outside, plus inside
Dimensions:
inside: o ca. 1.3 mm
outside: o ca. 3.5 mm
length: ca. 9.5 mm
Systémové požadavky
Devices with RS-232 interfaces
Obsah balení
Converter
Power supply
Mounting set for DIN rail
User manual
Balení
• Krabice
